Barriers at wall openings

shaft_openings_safetyrespect_5597

Using Wall brackets and Barriers can quickly and easily secure wall openings. Using this attachment there is no need for posts and attachment in the slab. The solution makes it simple and fast to open and close the edge protection. Casting is facilitated and one advantage is that repair of edge protection attachments are not required. This solution creates a tighter edge protection in comparison to using Adjustable link bars. It is quick and easy to install and uninstall when various kinds of work task are to be carried out.

PRODUCTS
• Wall bracket
• Barrier 1,3 L, 1,95 L, 2,6 L
• Barrier Bracket 360

shaft_openings_safetyrespect_4

shaft_openings_safetyrespect_0865

shaft_openingssafetyrespect_

shaft_openings_safetyrespect_086

Installation of floor structure

blocking_safetyrespect_7073c

When installing prefabricated concrete slabs a movable edge protection is required for safe blockage for other construction personnel. For this the Ground Support Plate is used together with Socket base, Post 1,3 m and Barrier 2,6 L. The Barriers then work as effective and safe blockage while the installation of prefabricated concrete slabs is carried out by workers with personal protection equipment.

PRODUCTS
• Ground support plate
• Socket base
• Post 1,3 m
• Barrier 1,3 L, 1,95 L, 2,6 L
• Personal Protection Equipment

blocking_safetyrespect_5548

blocking_safetyrespect_5577

blocking_safetyrespect_7073

Prefabricated concrete slabs

prefab_safetyrespect_9368c

When prefabricated concrete slabs are used in building constructions Socket base is usually installed at the slab edge for attachment of edge protection. In the Socket base Post 1,3 m is installed and thereafter Barrier 2,6 L. The Barrier can be raised in one simple operation on the post up to a height of 310 mm above the floor structure, without decreased safety. This creates conditions for joint grouting, casting and other common work tasks without any need of uninstalling the edge protection.

PRODUCTS
• Socket base
• Post 1,3 m
• Barrier 1,3 L, 1,95 L, 2,6 L
• Cast protection for Socket base

standard_system_0119

standard_system_safetyrespect_0114c

standard_system_safetyrespect_0136c

Socket base on slab edges

slaps_safetyrespect_0115

Slab edges are present everywhere and are a usual cause of fall accidents. Edge protection can be installed on the slab or on the outside of the slab edge. If there are columns, they can be an alternative attachment of the edge protection. Please see solutions for columns/beams.

Our solution can be installed on all types of material and they are very fast and flexible as, for example, when walls are to be installed. When the Barrier is in its lowest position it seals against the slab, and it can easily be raised on the post for various kinds of work at the slab edge.

Please see also our solutions for prefabricated materials.

PRODUCTS
• Socket base
• Vertical bracket
• Post 1,3 m
• Barrier 1,3 L, 1,95 L, 2,6 L

standard_system_0018

standard_system_safetyrespect_0136c

standard_system_safetyrespect_0114c

standard_system_safetyrespect_0112

standard_system_0119

concrete_slab_edges_safetyrespect_0136

standard_system_safetyrespect_0129

Attachment to the string

stairs_safetyrespect_p6300013c

As an attachment point for the bracket the regular cast in sockets in stairs can be used. A Stair bracket with spacers makes it possible to let the protection in the stairs during the whole construction period. All kinds of work can be carried out with the Adjustable Link Bars in place, even the final painting work.

PRODUCTS
• Stair bracket
• Post 1,3 m
• Adjustable link bar
• Barrier bracket 360

stair_bracket_safetyrespect_0051x

stair_bracket_safetyrespect_0052x

Attachment with Socket base

stairs_safetyrespect_3447c

The Socket base can be used as attachment of edge protection in stairs. The Socket base has an integrated bracket for Post 1,3 m. Adjustable link bars are installed on the posts.

PRODUCTS
• Socket base (with current anchorage)
• Post 1,3 m
• Adjustable link bar
• Barrier bracket 360

stairs_safetyrespect_3406

stairs_safetyrespect_3504

stairs_safetyrespect_3482

stairs_safetyrespect_3471

stairs_safetyrespect_3471c
